Yamaha MGX16 Digital Mixing Console in Black

The Yamaha MGX16 is a powerful and versatile digital mixing console designed for live sound, recording, podcasting, livestreaming, and installed audio applications. Combining Yamaha's renowned sound quality with intuitive touchscreen operation and extensive connectivity, it provides a flexible all-in-one mixing and recording solution for professionals and creators alike.

Featuring eight premium MGX microphone preamps, a 4.3-inch touchscreen, and a 15 + 1 fader layout, the MGX16 gives you intuitive hands-on control over 22 input channels. Its extensive mixing architecture includes eight mono channels, four stereo channels, a dedicated Sound Pad, and two FX return channels, supported by eight MIX buses and a stereo bus.

The onboard DSP engine provides professional-quality processing and effects, including Gate, Compressor, EQ, Reverb, Amp Simulator, Voice Changer, and more. Intelligent features such as Auto Gain, Clip Safe, Simple Mode, and Scene Recall help simplify setup and keep your workflow running smoothly.

For recording and production, the MGX16 offers a powerful 22-in/22-out USB MAIN interface at 32-bit/96kHz, alongside a separate USB SUB connection. Record up to 16 tracks directly to microSD card, play back audio, or connect wirelessly using Bluetooth® 5.0. With eight assignable sound pads, four headphone outputs, and extensive analogue connectivity, the MGX16 is ready for demanding live and studio applications.

Key Features

• 22-channel digital mixing console
• 15 + 1 non-motorised fader configuration
• 4.3-inch touchscreen with five control knobs
• 8 premium-quality MGX microphone preamps
• Input channels: 8 mono, 4 stereo, 1 Sound Pad and 2 FX returns
• 8 MIX buses and 1 STEREO bus
• Built-in DSP with professional effects and processing
• Auto Gain and Clip Safe for simplified setup and reliable levels
• Simple and Standard operating modes with Scene Recall
• 8 customisable sound pads and 4 assignable control knobs
• USB MAIN: 22 inputs / 22 outputs at 32-bit/96kHz
• USB SUB: 2 inputs / 2 outputs at 16-bit/48kHz
• 16-track microSD recording and 2-track playback at up to 24-bit/96kHz
• Bluetooth® 5.0 audio input
• Four headphone outputs for flexible monitoring
• Compact design for live sound, streaming, and studio production

Connectivity

• 8 x XLR/TRS combo microphone/line inputs
• 4 x TRS line inputs
• 4 x RCA line inputs
• 2 x XLR outputs
• 8 x TRS OMNI outputs
• 4 x TRS headphone outputs
• 2 x USB Type-C connections (MAIN and SUB)
• microSD card slot
• Bluetooth® 5.0 audio input

Included Software & Accessories

• Steinberg Cubase AI licence
• Steinberg WaveLab Cast licence
• Steinberg Plus
• Basic FX Suite licence
• Yamaha PA-300C AC power adapter
• Start Guide and Safety Guide
